*TRUCK-MOUNT ORDERS ARE PRE-ORDER! Once the order is placed we will reach out via email in regards to pick-up time.
Frame Footprint:
-
Width: 32.52" (2" Mounting Tabs)
-
Height: 30" (Clearance 36")
-
Length: 54.5" (Clearance 65")
Weight: 1080Lbs
Engine: GM Vortec 50HP
Battery: 48 Month
Vacuum: 5.9 Roots Tri-Lobe Blower
Inches of Life: 15 H.G.
CFM: Free Flow 850
Silencing: Low Blower Noise
Waste Disposal: Automatic Dump
Recovery: Stainless Steel Tank with Nylon Filter
Pressure Pump: General Pump 2500psi @4.2 G.P.M
Heat: Proprietary Heat Exchangers, Main Blower Exhaust
Gauges:
-
Voltmeter
-
Vacuum
-
Hourmeter
-
Temperature
-
High Pressure
-
Low Pressure
-
Oil Pressure
-
Tachometer
Hoses:
- 300ft 1/4" High Pressure Solution
-
300ft 2" Vacuum
Hose Reel: Double- 300ft
Installation: Approx. 3 hours
